One Series: Original Fungilab Viscometer. Essential viscosity measurement. |
Features:
-
• Friendly user.
-
• Relative and absolute viscosity.
-
• Unit converter SI to CGS.
Auto range:
Display of maximum measurable limits.
Displayed info:
Viscosity (cP or mPa•s) , % Torque , Spindle , Speed .
Auto-test:
It checks the internal function in order to make the unit ready to use.
Sound alarm:
Under or over range.
Universal adapter:
All accessories such as Brookfield (Optional).
Spindles:
AISI 316 stainless steel spindles, easily identified by number and letter when changed according to range of viscosity.
Standard Delivery:
Viscometer head with serial number / Stand, 3 levelling adjustment for stand / Boss head / Standard spindles / Spindle protector / Spindle rack / Power supply cable / Calibration Certificate / Operating manual. |
Technical Specifications:
VISCOLEAD ONE |
|
Code |
Model |
Measuring Range (cP) |
Speed (r.p.m) |
Number of speeds |
Accuracy |
Resolution |
Repeatability |
|
V100003 |
ONE L |
20 - 2.000.000 |
0.3 - 100 |
18 |
± 1% of full scale. |
Low viscosity adapter: 0.01 For lower than 10.000 viscosity cP: 0.1 For viscosity equal to or above 10.000 cP: 1 |
0.2% |
|
V100002 |
ONE R |
100 - 13.000.000 |
0.3 - 100 |
18 |
|
V100001 |
ONE H |
200 - 106.000.000 |
0.3 - 100 |
18 |
|
 |
|
Adv Series: Advance viscosity measurement. User friendly. |
Features:
-
• Friendly user.
-
• Relative and absolute viscosity.
-
• Unit converter SI to CGS.
Data displayed:
-
• Selected speed.
-
• Selected spindle.
-
• Viscosity reading: cP (mPa•s) or cSt.
-
• Percentage of full scale Range (%).
-
• Sample temperature: oC or oF (Optional).
-
• Temperature reading by PT100 (optional).
Viscosity readings:
-
• Absolute viscosity (cP or mPa•s).
-
• Apparent viscosity (cP or mPa•s).
-
• Kinematics viscosity (cSt, mm2/sec).
-
• Density introduced by the user.
USB interface:
Faster tranfer data to the computer.
Datalogger Software included:
USB allows data transfer to a PC Excel format.
Universal adapter:
All accessories such as Brookfield (optional).
Spindles:
AISI 316 stainless steel spindles, easily identified by number and letter when changed according to range of viscosity.
Standard Delivery:
Viscometer head with serial number / Stand, 3 levelling adjustment for stand / Boss head / Standard spindles / Spindle protector / Spindle rack / PT100 probe (optional) / Power supply cable / Datalogger software in a CD / USB cable / Carrying case / Calibration Certificate / Operating manual. |
Technical Specifications:
VISCOLEAD ADV |
|
Code |
Model |
Measuring Range (cP) |
Speed (r.p.m) |
Number of speeds |
Accuracy |
Resolution |
Repeatability |
|
V200003 |
ADV L |
20 - 2.000.000 |
0.3 - 100 |
18 |
± 1% of full scale. |
With low viscosity adapter: 0.01 For lower than 10.000 viscosity cP: 0.1 For viscosity equal to or above 10.000 cP: 1 |
0.2% |
|
V200002 |
ADV R |
100 - 13.000.000 |
0.3 - 100 |
18 |
|
V200001 |
ADV H |
200 - 106.000.000 |
0.3 - 100 |
18 |
|
|
Thermometer features: |
|
Temperature |
Type of probe |
Resolution |
Repeatability |
0ºC to +100ºC
32ºF to 212.0ºF |
PT100 |
0.1ºC / 0.1722 oF |
+/- 0.1ºC |
|
 |
|
Pro Series: Professional and Accurate viscosity results. Customize your measurement. |
Features:
-
• Friendly user.
-
• Relative and absolute viscosity.
-
• Unit converter SI to CGS.
Program features:
-
• Time to torque.
-
• Time to stop.
-
• 10 working memories.
-
• Customizable option (Speeds).
-
• Programmable: Multistep/Ramp.
-
• Unit Converter (IS or CGS).
USB interface: Faster transfer data to the computer.
Auto-test: It checks the internal function in order to make the unit ready to use
Viscosity readings:
-
• Absolute viscosity (cP or mPa•s).
-
• Apparent viscosity (cP or mPa•s).
-
• Kinematic viscosity (cSt, mm2/sec).
-
• (Density introduced by the user).
10 working memories:
Set up the unit and get it ready to be used every day choosing the memory you need.
Data displayed:
-
• Selected speed.
-
• Selected spindle.
-
• Viscosity readings (cP or mPa•s or cSt).
-
• Percentage of full scale Range (%).
-
• Sample Temperature (OC or OF)
-
• Shear rate (with coaxial spindles) (s-1).
-
• Shear Stress (with coaxial spindles) (N/m2).
-
• Density (introduced by the user) (g/cm3).
Universal adapter:
All accessories such as Brookfield (optional).
Datalogger Software included:
USB allows data transfer to a PC Excel format.
Spindles:
AISI 316 stainless steel spindles, easily identified by number and letter when changed according to range of viscosity.
Standard Delivery:
Viscometer head with serial number / Stand, 3 levelling adjustment for stand / Boss head / Standard spindles / Spindle protector / Spindle rack / PT100 probe / Power supply cable / Datalogger software in CD / USB cable / Carrying case / Calibration Certificate / Operating manual. |
|
Code |
Model |
Measuring Range (cP) |
Speed (r.p.m) |
Number of speeds |
Accuracy |
Resolution |
Repeatability |
|
V400003 |
PRO L |
20 - 6.000.000 |
0.1 - 200 |
54 |
± 1% of full scale. |
With low viscosity adapter: 0.01 For lower than 10.000 viscosity cP: 0.1 For viscosity equal to or above 10.000 cP: 1 |
0.2% |
|
V400002 |
PRO R |
100 - 40.000.000 |
0.1 - 200 |
54 |
|
V400001 |
PRO H |
200 - 106.000.000 |
0.1 - 200 |
54 |
|
|
Thermometer features: |
|
Temperature |
Type of probe |
Resolution |
Repeatability |
0ºC to +100ºC
32ºF to 212.0ºF |
PT100 |
0.1ºC / 0.1722 oF |
+/- 0.1ºC |
|
All the Units Conform to Following Standards:
BS:6075,5350, ISO:2555,1652, ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716
Languages options:
English / French / German / Catalan / Spanish / Italian / Japanese / Polish / Dutch / Portuguese |
