SAND BATH PRAZITHERM
Electrical sand baths with variable temperature control, with or without a thermostatic controller.
Robust construction for continuous performance.
Aluminium alloy hotplate. Because of the asymmetrical, long-term heating system (hotplate corners and edges are subjected to more heat) an even temperature is guaranteed over the entire heating surface.
The sand baths consist of an aluminium alloy hotplate with a screwed-on, sealed stainless steel frame with a usable height of 50 mm.
The sand lays direct of the hotplate.
The housing is constructed from high-grade, stainless steel No.1.4301, whereby the central section has been additionally sprayed in orange.
4 adjustable feet ensure extra stability.
Connecting cable approx. 1, 7 m long, 230 Volt/3200 Watt with Schuko plug.
|
Sandbaths with Performance Control: |
|
Type |
Watt |
Volt |
Temperature |
A
mm |
B
mm |
C
mm |
D
mm |
Weight
kg |
|
SD 7
|
2200 |
230 |
max. 370°C |
360 |
360 |
358 |
358 |
13 |
|
SD 8 |
2850 |
230 |
max. 370°C |
360 |
510 |
364 |
514 |
21 |
|
SD 9-230 |
4000 |
230 |
max. 370°C |
440 |
590 |
442 |
592 |
27 |
|
SD 9-400 |
4000 |
3x400,N+PE |
|
Sandbaths with Performance Control and Thermostatic Controller: |
|
Type |
Watt |
Volt |
Temperature |
A
mm |
B
mm |
C
mm |
D
mm |
Weight
kg |
|
ST 71 |
1150 |
230 |
30 - 110°C |
360 |
360 |
358 |
358 |
14 |
|
ST 72 |
2200 |
230 |
50 - 300°C |
|
ST 73 |
2200 |
230 |
130 - 370°C |
|
ST 81 |
1800 |
230 |
30 - 110°C |
360 |
510 |
364 |
514 |
21 |
|
ST 82 |
2850 |
230 |
50 - 300°C |
|
ST 83 |
2850 |
230 |
130 - 370°C |
|
ST 91 |
2000 |
230 |
30 - 110°C |
440 |
590 |
442 |
592 |
28 |
|
ST 92-230 |
4000 |
230 |
50 - 300°C |
|
ST 92-400 |
4000 |
3x400,N+PE |
50 - 300°C |
|
ST 93-230 |
4000 |
230 |
130 - 370°C |
|
ST 93-400 |
4000 |
3x400,N+PE |
130 - 370°C |
